Truck Mounted Roots Blower

Get a Price/Quote

MOQ : 1 Unit

Truck Mounted Roots Blower Specification

Pressure Range
0.5-1.2 bar

Max Pressure
1.2 bar

Life Span
Up to 10 Years

Motor Power
40 HP

Power
30-55 kW

Flow Rate
2500-4500 m³/hr

Output Power
40 kw

Vaccum Range
Up to -0.5 bar

Product Type
Roots Blower

Material
Mild Steel

Capacity
2500-4500 m³/hr

Pressure
0.8-1 bar

Application
Bulk material unloading from trucks, pneumatic conveyors, dewatering, industrial use

Frequency (MHz)
50

Motor Speed
1450 RPM

Noise Level
Below 85 dB

Power Source
Electric

Voltage
415 V

Weight
1350 kg

Dimension (L*W*H)
2200 x 1200 x 1100 mm

Color
Blue

Discharge Connection Size
100-150 mm

Drive Type
Belt Driven

Automatic Grade
Semi Automatic

Intake Temperature
Max 45C

Ambient Temperature
-10C to 50C

Shaft Seal
Oil Seal

Enclosure Type
Weatherproof

Cooling Type
Air Cooled / Water Cooled

Maintenance
Low Maintenance

Mounting Type
Truck Mounted

Lubrication System
Splash Lubrication

Standard Accessories
Silencer, Suction Filter, Pressure Relief Valve

Truck Mounted Roots Blower Trade Information

Minimum Order Quantity
1 Unit

FOB Port
Mundra

Supply Ability
20 Units Machine Per Month

Delivery Time
30 Days

Packaging Details
Wooden Box Packaging

Main Export Market(s)
Africa, Asia

Main Domestic Market
All India

About Truck Mounted Roots Blower

supplier of a wide range of Truck Mounted Roots Blowers. These products are specifically manufactured using superior grade raw material, which is sourced from renowned vendors of the industry. Designed and developed in strict compliance with set industry standards and norms, the range is cross examined before final dispatch so that our clients receive a range that is free from any sort of defect. Available in standard and customized forms, our range finds its extensive usage in varied industries.

Features:

Reliable
Durable

Versatile and Robust Performance

This truck-mounted roots blower is engineered to efficiently handle pneumatic conveying, dewatering, and bulk material unloading. Its durable construction is designed to withstand the varying demands of industrial and logistics applications, operating reliably in ambient temperatures from -10C to 50C.

Flexible Cooling and Drive Options

Choose between air-cooled or water-cooled configurations to suit different operational environments. The belt-driven design allows for smooth torque transmission, while the splash lubrication system ensures sustained low-maintenance performance even under continuous use.

Safety and User-Friendly Features

Equipped with oil shaft seals, a weatherproof enclosure, and standard safety accessories such as a silencer, suction filter, and pressure relief valve, this blower provides safe and quiet operation. Its semi-automatic automatic grade prioritizes ease of use and minimal supervision, making it well-suited for a range of industries.

FAQs of Truck Mounted Roots Blower:

Q: How is the truck mounted roots blower maintained?

A: This blower requires minimal maintenance due to its splash lubrication system and belt-driven design. Regular checks on the silencer, suction filter, and pressure relief valve are recommended for optimal performance.

Q: What are the typical applications for the truck mounted roots blower?

A: It is widely used for unloading bulk materials from trucks, supporting pneumatic conveyors, performing dewatering tasks, and serving various industrial operations requiring efficient air movement.

Q: When should I select air-cooled versus water-cooled variants?

A: Choose air-cooled models for ambient temperature operations and moderate loads. Opt for water-cooled versions when high ambient temperatures or heavy-duty, continuous operation is expected, ensuring efficient thermal management.

Q: Where can the truck mounted blower be installed?

A: This blowers weatherproof enclosure makes it suitable for outdoor and on-vehicle installations, particularly mounted onto trucks, even in challenging weather conditions.

Q: What is the operating process of the roots blower?

A: The blower works by drawing air through a suction filter, compressing it for discharge via a belt-driven mechanism. It is semi-automatic, requiring minimal human intervention once operational.

Q: What are the benefits of using this blower for bulk material unloading?

A: It ensures rapid, clean, and efficient unloading by providing a reliable flow of air, reducing manual labor, limiting spillage, and minimizing material loss during transfer.
